 Daikoku bonding wire
漆包
 Daikoku bonding wire
漆包
Daikoku bonding wire
Feature
*With lean management of the Japan production line, we provide ultra-fine diameter from 0.01~0.15mm for precision products.

*Up to 200°C heat resistance bonding film material that is suitable for varies applications from VCM, speakers to microphone.

*Over 70 years of production experience and quality assurance.

・ Speaker Coils
・ Microspeaker Coils
・ Headphone Coils
・ Earphone Coils
・ Pickup Coils
・ VCM
・ Vibration Coils

fig3-1.Cross section of CCA conductor

fig3-2.Stress - Strain Curve of Self-bonding wires (Class2 0.080mm)
